Atlona AT-HD88M-SR User Manual
Page 21
19
1. Press SELECT button until the LED shows
to enter the EDID Learning Mode.
2. Wait for 2 seconds until the all LED from port 1 to port 8 display
, which means to hold the
default EDID profile in EDID learning mode, not panel hold mode (Mode H).
3. Press “” or “
—” button on PORT1 to PORT8 to select the EDID profile you decide to use on
each HDMI input port. Please make sure the displays and the receiver units are all power on
and connected.
Sequence for pressing “” button:
,
,
,
,
,
,
,
,
,
,
,
,
,
Sequence for pressing “
—” button:
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,or
means you select to learn the EDID of the display connected
to respect HDMI output port.
means you select type-A default EDID profile (720p) to be used on the HDMI input port.
means you select type-B default EDID profile (1080p) to be used on the HDMI input port.
means you select type-C default EDID profile (1080p) to be used on the HDMI input port.
means you select type-D default EDID profile (720p) to be used on the HDMI input port.
4. Once you finish the EDID configuration for each HDMI input port, press SAVE button.
5. After a couple seconds, the LED on PORT 1 to PORT 8 will display either
meaning OK or
meaning failed for the EDID learning procedure on each HDMI input port.
