065-1800 series Hardened Media Converter
User’s Manual 11
Specifications
Applicable Standards IEEE 802.3 10BaseT
IEEE 802.3u 100BaseTX & 100BaseFX
Fixed Ports 1 TX port, 1 FX port
10/20Mbps for half/full-duplex Speed 10BaseT
100BaseTX/FX 100/200Mbps for half/full-duplex
Switching Method Store-and-Forward
Forwarding rate 14,880/148,800pps for 10/100 Mbps
Cable
10BaseT
100BaseTX
100BaseFX 2-pair UTP/STP Cat. 3, 4, 5 up to 100m
2-pair UTP/STP Cat. 5 up to 100m
MMF (50 or 62.5µm), SMF (9 or 10µm)
Per Unit- (4 LEDs):
PWR1, PWR2, FAULT, LFP
LED Indicators
Per Port-
TX (3 LEDs): LNK/ACT, FDX/COL, 100
FX (2 LEDs): LNK/ACT, FDX/COL
Dimensions W50 × D110 x H136 mm
Weight 0.6 Kg
Power
DC Jack: 3A 12VDC, External AC/DC
required
Terminal Block: 1.5A 24VDC, 10-48VDC
Power Consumption 4.8W Max.
Operating Temperature - 40°C ~ 74°C
Storage Temperature -45°C ~ 93°C
Humidity 10 ~ 95%, non-condensing
Safety UL 60950, EN60950, IEC 60950,
IEC 61000-6-2
Emissions FCC Part 15, Class A
CE: EN55022 (CISR22 Class A)
EN55024 (CISPR24 Class A)
Standards
ESD Standard (IEC 61000-4-2)
Radiated FRI Standards (IEC 61000-4-3)
Burst Standards (IEC 61000-4-4)
Surge Standards (IEC 61000-4-5)
Induced RFI Standards (IEC 61000-4-6)
Magnetic Field Standards (IEC 61000-4-8)
Voltage Dips Standards (IEC 61000-4-11)
