Programming Manual C-1
APPENDIX C
SAMPLE PROGRAMS
The following examples will illustrate how to perform certain functions on the CW-P
using SCPI via the GPIB interface or the RS-232 channel.
NOTE: See the CW-P Series Operation Manual for examples of how to use
Slave commands.
1. Source AC from power up
SOUR:VOLT:RANGE LOW Specify low range 0-156V 13 Amps
SOUR:CURR 3 Specify 3 Amps current limit; foldback mode
SOUR:VOLT 120 Specify 120 VAC setpoint
SOUR:FREQ 60 Specify 60 Hz frequency
OUTP ON Source power to the output
2. Turn off Front Panel Programmability
SYST:KLOCK ON (1) Lock the program keys out
3. Turn on Front Panel Programmability
SYST:KLOCK OFF (0) Front panel program keys now function
4. Provide Zero Crossing pulses from Phase A
SYST:EXT:CLOCK OUT
5. Phase Lock Loop clock input
SYST:EXT:CLOCK IN
6. Turn on External Analog Gain control
SYST:EXT:ANAIN ON (1)
7. Turn off External Analog Gain control
SYST:EXT:ANAIN OFF (0)
