17
Group
Name
CmdResp Description
Read /
Write
Min
Value
Max
value
Default
value
Values
Index #1
Index #2
SIG_FORMAT_LIST
sL
sL
Bit field of the fomats compatible with
the detected format
Rd
0
255 0
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
0 = Bits 0 to 7
Slice
1 = Bits 8 to 15
Slice
2 = Bits 16 to 23
Slice
3 = Bits 24 to 31
Slice
4 = Bits 32 to 39
Slice
5 = Bits 40 to 47
Slice
SIG_SCANTYPE
ss
ss
Input scan type
Rd
0
3
0
0 = Progressive
1 = Interleaved, Top field first
2 = Interleaved, Bottom field first
3 = Segmented frame
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
SIG_HTOTAL_THEORIC
sH sH
Total number of pixels per line
Rd
0
655350
Unit = pixels
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
SIG_HTOTAL_MAXI
sM sM Maximal number of pixels per input line Rd
0
655350
Unit = pixels
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
