Group
Name
CmdResp Description
Read /
Write
Min
Value
Max
value
Default
value
Values
Index #1
Index #2
PE_SIZE_H
pW pW
Layer H size on output screen (without
borders)
Rd/Wr 0
655351600
Unit = pixels ( Max=16x2048 = 32768)
0 = Current preset
1 = Next preset
2 = Previous
preset
3 = Memory Preset
1
4 = Memory Preset
2
5 = Memory Preset
3
6 = Memory Preset
4
2 = Background
Layer for output 1
3 = Pip 1 Layer for
output1
Background Layer
for output 2 in
matrix mode
8 = Audio Output 1
9 = Audio Output 2
PE_SIZE_V
pS pS
Layer V size on output screen (without
borders)
Rd/Wr 0
655351200
Unit = pixels (Max=16x2048 = 32768)
0 = Current preset
1 = Next preset
2 = Previous
preset
3 = Memory Preset
1
4 = Memory Preset
2
5 = Memory Preset
3
6 = Memory Preset
4
2 = Background
Layer for output 1
3 = Pip 1 Layer for
output1
Background Layer
for output 2 in
matrix mode
8 = Audio Output 1
9 = Audio Output 2
PE_CROP_WIN_POS_H
CH CH Cropping window horizontal position
Rd/Wr 0
6553532768
Unit = percent ( 65535 = 100% = : all
cropping on the left )
0 = Current preset
1 = Next preset
2 = Previous
preset
3 = Memory Preset
1
4 = Memory Preset
2
5 = Memory Preset
3
6 = Memory Preset
4
2 = Background
Layer for output 1
3 = Pip 1 Layer for
output1
Background Layer
for output 2 in
matrix mode
8 = Audio Output 1
9 = Audio Output 2
