39
Group Name CmdResp Description
Read /
Write Min
Value Max
value Default
value
Values Index #1 Index #2
REFCURRENTREQUEST Xe Xe Current Frame Lock source Rd/Wr 0 15 0
0 = Analog input 1 as reference
1 = Analog input 2 as reference
2 = Analog input 3 as reference
3 = Analog input 4 as reference
4 = Analog input 5 as reference
5 = Analog input 6 as reference
8 = DVI 1 input as reference
9 = DVI 2 input as reference
10 = SDI 1 input as reference
11 = SDI 2 input as reference
14 = Back End 1 as reference
15 = Back End 2 as reference
0 = Main output
1 = Preview output
REFMODE Xm Xm Follow mode requested by user Rd/Wr 0 5 0
0 = Internal
1 = Follow x1/2
2 = Follow x1
3 = Follow x2
4 = Follow x3
5 = Asynchronous Follow
0 = Main output
1 = Preview output
REFCURRENTMODE Xc Xc Current follow mode Rd/Wr 0 5 0
0 = Internal
1 = Follow x1/2
2 = Follow x1
3 = Follow x2
4 = Follow x3
5 = Asynchronous Follow
0 = Main output
1 = Preview output
REFFREQ Xt Xt Frame rate of the reference signal Rd 0 655350 Unit = 1/100Hz
0 = Main output
1 = Preview output
REFLOCKSTATUS Xl Xl Framelock locked status Rd 0 1 0 1 = locked
0 = Main output
1 = Preview output
LAN
LANENABLE ne ne LAN enable Rd/Wr 0 1 0
0 = Enable RS232 ( disable LAN )
1 = Enable LAN ( disable RS232 )
LANRESET nr nr LAN factory parameters reset Rd/Wr 0 1 0 Auto reset
LANSTORE ns ns LAN parameters update Rd/Wr 0 1 0 Auto reset
LANIP nw nw LAN devices addresses Rd/Wr 0 255 192 IP : 0 to 255
0 = Device
1 = Remote
2 = Gateway
0 = IP address
high byte
1 = IP address mid
high byte
2 = IP address mid
low high byte
3 = IP address low
byte
LANPORT np np LAN port numbers Rd/Wr 0 6553510500
Local port : 10000 à 10999
Remote port : 0 à 65500
0 = Device
1 = Remote
2 = Gateway
LANNETMASK nk nk LAN netmask Rd/Wr 0 24 8 Number of 0bits from the right
