Analog Way Smart MatriX LE - SMX100 Programmer's Guide - Manual (Page 18)

18
Group Name CmdResp Description
Read /
Write Min
Value Max
value Default
value
Values Index #1 Index #2
SIG_WIDTH sw sw Input displayed pixel count Rd 0 655350 Unit = pixels
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
SIG_HEIGHT st st Input displayed line count Rd 0 655350 Unit = pixels
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
SIG_HDCP sn sn Input HDCP status Rd 0 1 0
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
SIG_MEM_SLOT sS sS Memory slot index Rd 0 255 255
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
