Analog Way Smart MatriX LE - SMX100 Programmer's Guide - Manual (Page 32)

32
Group Name CmdResp Description
Read /
Write Min
Value Max
value Default
value
Values Index #1 Index #2
PE_OPENING_TRANSITION oT oT Layer opening transition type Rd/Wr 0 2 2
0 = Cut
2 = Fade
0 = Current preset
1 = Next preset
2 = Previous
preset
3 = Memory Preset
1
4 = Memory Preset
2
5 = Memory Preset
3
6 = Memory Preset
4
2 = Background
Layer for output 1
3 = Pip 1 Layer for
output1
Background Layer
for output 2 in
matrix mode
8 = Audio Output 1
9 = Audio Output 2
PE_OPENING_TRANSITION_WAY oW oW Layer opening transition direction Rd/Wr 0 10 0
0 = Current preset
1 = Next preset
2 = Previous
preset
3 = Memory Preset
1
4 = Memory Preset
2
5 = Memory Preset
3
6 = Memory Preset
4
2 = Background
Layer for output 1
3 = Pip 1 Layer for
output1
Background Layer
for output 2 in
matrix mode
8 = Audio Output 1
9 = Audio Output 2
PE_OPENING_DURATION oD oD Layer opening transition duration Rd/Wr 0 255 10 Unit = 1/10s
0 = Current preset
1 = Next preset
2 = Previous
preset
3 = Memory Preset
1
4 = Memory Preset
2
5 = Memory Preset
3
6 = Memory Preset
4
2 = Background
Layer for output 1
3 = Pip 1 Layer for
output1
Background Layer
for output 2 in
matrix mode
8 = Audio Output 1
9 = Audio Output 2
