Analog Way Smart MatriX LE - SMX100 Programmer's Guide - Manual (Page 33)

33
Group Name CmdResp Description
Read /
Write Min
Value Max
value Default
value
Values Index #1 Index #2
PE_CLOSING_TRANSITION cT cT Layer closing transition type Rd/Wr 0 2 2
0 = Cut
2 = Fade
0 = Current preset
1 = Next preset
2 = Previous
preset
3 = Memory Preset
1
4 = Memory Preset
2
5 = Memory Preset
3
6 = Memory Preset
4
2 = Background
Layer for output 1
3 = Pip 1 Layer for
output1
Background Layer
for output 2 in
matrix mode
8 = Audio Output 1
9 = Audio Output 2
PE_CLOSING_TRANSITION_WAY cW cW Layer closing transition direction Rd/Wr 0 10 0
0 = Current preset
1 = Next preset
2 = Previous
preset
3 = Memory Preset
1
4 = Memory Preset
2
5 = Memory Preset
3
6 = Memory Preset
4
2 = Background
Layer for output 1
3 = Pip 1 Layer for
output1
Background Layer
for output 2 in
matrix mode
8 = Audio Output 1
9 = Audio Output 2
PE_CLOSING_DURATION cD cD Layer closing transition duration Rd/Wr 0 255 10 Unit = 1/10s
0 = Current preset
1 = Next preset
2 = Previous
preset
3 = Memory Preset
1
4 = Memory Preset
2
5 = Memory Preset
3
6 = Memory Preset
4
2 = Background
Layer for output 1
3 = Pip 1 Layer for
output1
Background Layer
for output 2 in
matrix mode
8 = Audio Output 1
9 = Audio Output 2
PRESET
CONTROL
TAKE TK TK TAKE, Next preset becomes Current Rd/Wr 0 1 0
TAKEAVA TA TA Available TAKE flag Rd 0 1 1
TAKEINFO TI TI TAKE information Rd 0 2 0
0 = 1 shot TAKE
1 = 2 shot TAKE
2 = Sequenced TAKE
TBAR NT NT TBAR value Rd/Wr 0 100000 Unit = 0,01%
