ARCHMI-9XX Series User Manual 29
Pin2 BAT2_LED-
Pin3 Ground
Pin4 RST_EC
11. DC_IN1:
(5.08mm Pitch 1x3 Pin Connector), DC9V~36V System power input connector.
Pin# Signal Name
Pin1 DC+9V~36V
Pin2 Ground
Pin3 FG
Model DC_IN1
SBC-7110-i34010U-4G 180°Connector
SBC-7110-I54310U-4G 180°Connector
SBC-7110-I74510U-4G 180°Connector
SBC-7110-I34010UP-4G 45°Connector
SBC-7110-I54310UP-4G 45°Connector
SBC-7110-I74510UP-4G 45°Connector
12. BT1/BT2:
Power on/off button, They are used to connect power switch button. The two
pins are disconnected under normal condition. You may short them
temporarily to realize system startup & shutdown or awaken the system from
sleep state.
13. LED2/LED3/LED4/LED5:
LED2: LED STATUS. Green LED for Motherboard EC status.
LED3: LED STATUS. Green LED for Power status.
LED4: LED STATUS. Green LED for Motherboard Standby Power Good status.
LED5: LED STATUS. Green LED for CPU1 status
14. HDMI1:
(HDMI 19P Connector), High Definition Multimedia Interface connector.
