Artesyn Centellis 4410 (AXP-1410) Installation and Use (July 2014) - Manual (Page 114)

Configuring and Operating the System
AXP 1410 Installation and Use (6806800H70L) 114
5.2.3.1 Setting the Shelf Address
Setting the Shelf Address on the Shelf Manager Boards (SAM 1410)
To set the shelf address in a shelf, proceed as follows:
1. Modify the shelf address using the rotary switches. For more information, refer to Rotary
Switch Settings on page 92 .
2. Power down and power up the shelf.
This ensures that all system components are aware of the new shelf address.
The change of shelf address, shelf IP address and FRU activation order takes effect after a
reboot of the system.
Two shelf manager boards in the same shelf must always be set to the same SGA. Otherwise.
the software detects that the FRU information in the two shelf manager boards is different
and stops the power-up process. The red LED blinks and the boards are not powered.
For information on how the shelf address is retrieved in certain scenarios and for
troubleshooting tips, refer to <shelf address reading behavior on page >
