Pin Assignments
MVME51005E Single Board Computer Installation and Use (6806800A38D) 108
17 PMC2_17 (P2-Z11) PMC2_18 (P2-D12) 18
19 PMC2_19 (P2-D13) PMC2_20 (P2-Z13) 20
21 PMC2_21 (P2-D14) PMC2_22 (P2-D15) 22
23 PMC2_23 (P2-Z15) PMC2_24 (P2-D16) 24
25 PMC2_25 (P2-D17) PMC2_26 (P2-Z17) 26
27 PMC2_27 (P2-D18) PMC2_28 (P2-D19) 28
29 PMC2_29 (P2-Z19) PMC2_30 (P2-D20) 30
31 PMC2_31 (P2-D21) PMC2_32 (P2-Z21) 32
33 PMC2_33 (P2-D22 PMC2_34 (P2-D23) 34
35 PMC2_35 (P2-Z23) PMC2_36 (P2-D24) 36
37 PMC2_37 (P2-D25) PMC2_38 (P2-Z25 38
39 PMC2_39 (P2-D26) PMC2_40 (P2-D27) 40
41 PMC2_41 (P2-Z27) PMC2_42 (P2-D28) 42
43 PMC2_43 (P2-D29) PMC2_44 (P2-Z29) 44
45 PMC2_45 (P2-D30) PMC2_46 (P2-Z31) 46
47 Not Used Not Used 48
49 Not Used Not Used 50
51 Not Used Not Used 52
53 Not Used Not Used 54
55 Not Used Not Used 56
57 Not Used Not Used 58
59 Not Used Not Used 60
61 Not Used Not Used 62
63 Not Used Not Used 64
Pin Assignment Pin
