4.3.2 Power Requirements
Make sure that the board is used in an AdvancedTCA shelf connected to -48VDC up to -60VDC
(rated voltage), according to Telecommunication Network Voltage (TNV-2).
A TNV-2 circuit is a circuit whose normal operating voltages exceed the limits for a safety-extra-
low-voltage (SELV) under normal operating conditions, and which is not subject to
overvoltages from telecommunication networks.
Table 4-1 Environmental Requirements
Feature Operating Non-Operating (packed state)
Temperature +5ºC (+41°F) to +40ºC (+104°F) (normal
operation) according to NEBS Standard
GR-63-CORE
-5°C (+23°F) to + 55°C (+131°F)
(exceptional operation) according to
NEBS Standard GR-63-CORE -40ºC (-40°F) to +85ºC (+185°F)
Temp. change +/- 0.25ºC/min according to NEBS
Standard GR-63-CORE +/- 0.25ºC/min
Relative humidity 5% to 90% non-condensing according to
Artesyn Embedded Technologies-
internal environmental requirements 5% to 95% non-condensing according
to Artesyn Embedded Technologies-
internal environmental requirements
Vibration (tested
in target platform) 0.1 g from 5 to 100 Hz and back to 5 Hz
at a rate of 0.1 octave/minute. 5-20 Hz at 0.01 g
2
/Hz
20-200 Hz at -3.0 dB/octave
Random 5-20 Hz at 1 m
2 /Sec 3
Random 20-200 Hz at -3 dB/octave
Shock Half-sine, 11 mSec, 30 m/Sec 2 Blade level packaging
Half-sine, 6 mSec at 180 m/Sec
2
Free fall - 1.0 m (packaged) per ETSI 300 019-2-
2
(Blade level packaging)
100 mm (unpackaged) per GR-63-
CORE
