Knife Parts List
Item
Part
No.
Description Qty
1 421002 FRONT PLATE 1
2 427018 SUPPORT, ROCKER ARM 1
3 422012 LINK PLATE ASSEMBLY 2
4 427033 LINK SLIDER ASSEMBLY 1
5 427041 SCREW, KNIFE ADJUSTER 1
6 427007 TIE PLATE 1
7 427042 LOCK KNOB 1
8 427026 NUT, ADJUSTMENT 1
9 421012 FRAME, KNIFE 1
10 427002 SLIDER, KNIFE ADJUST 2
11 427062 INSULATOR, KNIFE HOLDER 2
12 427061 BUSHING, INSULATOR 2
13 990092 10-32 X 1/2" BUTTON HD CAP SCR 2
14 990122 1/4-20 X 3/4" SOCKET HD CAP SCR 2
15 999142 BUSHING, 1/2 X 3/4 X 2" 2
Item
Part
No.
Description Qty
16 990120 1/4-20 X 1/2" SOCKET HD CAP SCR 6
17 990127 1/4-20 X 2" SOCKET HD CAP SCR 2
18 990148 1/4-20 E-S NUT 1
19 427035 COMPRESSION SPRING 1
20 990081 10-32 X 1/2 SOCKET HJD CAP SCR 2
21 151186 SONIC CONTROL IMPUT HARNESS 1
22 989976 #6 STAR WASHER 1
23 990019 6-32 X 1/4" BUTON HD CAP SCR 1
24 575004 SONIC KIT, 115V, 1000W 1
25 427096 FRAME, HORN MOUNT 1
26 577056 KNIFE BLADE 1
27 427086 KNIFE MOUNT 1
28 999071 BUSHING 5/16 X 1/2 X 3/8" 1
29 999105 BUSHING 5/16 X 7/16 X 1/4" 1
30 427006 ARM, LEVER 1
