24 DR
®
ROTO-HOG™ Mini Tiller
Parts List - Engine Assembly
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
01 Flywheel, Magneto
02 Nut, Flange M8
03 Washer, Rotor
04 26169 Clutch Rotor Assembly
05 Spring, Clutch
06 Washer, Spring
07 Bolt, Shoulder
08 Pin, Locating
09 Mount Ring & Shroud
10 Recoil, Clutch
11 Plate, Recoil
12 Handle, Standard Recoil
13 26170 Recoil Assembly w/Standard Handle
14 25916 Ignition Coil
15 26171 Shroud, Engine
16 Bolt, Stud, M6 x 62mm
17 Gasket, Muffler
18 26172 Muffler
19 26173 Cover,
Muffler
20 13036 Spark Plug
21 Cover, Engine Shroud
22 Gasket, Intake
23 Windpipe, Intake
24 Gasket, Carburetor
25 26175 Carburetor
26
O-Ring, Carburetor
27 26176 Primer Bulb
28-31 Intake Base Assembly
29 Choke Lever, Long
30 Cover, Choke
31 Screw, Throttle Lever
32 Plate, Intake Cover Adapter
33 Cover, Air Filter
34 Air Filter
35 Cover, Intake
36 Bracket, Fuel Tank
Ref# Part# Description
37 26050 Fuel Tank
38 26049 Fuel Cap, Manual Venting
39 Shroud, Fuel Tank
40 26177 Switch, Rocker
41 Grommet, 2-Hole, Fuel Tank
42 Hose, Primer Line
43 Hose, Fuel Line
44 Bolt w/Washer, Phillips, HH
45 Nut, Flange, M6
46 26139 Bolt w/Washer, M5 x 12mm
47 Bolt w/Washer, Pan Head, M5 x 18mm
48 Bolt, M5 x 18mm, HH
49 Bolt w/Washer, M5 X 25mm
50 Bolt M5 x 50mm
51 Guard
52 Key, Flywheel
53 26178 Filter, Fuel
54 Bolt, Stud, M6 x 41mm
55 23651 Key, Electric Starter
56 Wire, Starter
57 Starter Motor Kit (includes Starter, Stud
Bolt, Clutch Drum & Ground Wire)
58 Washer, M5
59 Bolt, w/Washer, M5 x 25mm
60 Bolt, w/Washer, Pan Head, M5 x 18mm
61 Cover, Air Filter
62 26179 Base, Air Filter (includes items 65-69)
63 26180 Air Filter, Foam
64 Plate, Reinforcement
65 Bolt, Choke Lever
66 Washer, Choke Lever
67 Nut, Lock, Nylon, Choke Lever
68 Lever, Choke
69 Paddle, Choke
Not Illustrated:
26181 Fuel Line Hose & Filter Assembly
(includes Items 43 & 53)
