Page 20
HYDRA NH
4
+
-N
Ch 1 Setup Menu,
cont’d
1 On > 10.00 ppm
1 Off < 9.500 ppm
Timer 1 : oneshot↑
Now 0 00 :00 :00
On 0 00 :00 :00
Off 0 00 :01 :30
Ks 0.10
K+ comp On
TC .333 %/°C
Isopot XXX.X mV
Equilib 9.24 pH
Dissoc 1.000 On
Noise filter 5
Ch 2 Setup Menu
Settings
Settings
TC .333 %/°C
Isopot XXX.X mV
Noise filter 5
Ch 3 Setup Menu
Settings
Settings
4mA 2.00 pH
20mA 12.00 pH
1 On > 7.50 pH
1 Off < 7.40 pH
Noise filter 5
4.1.3 Configure and Trim Menu, Standard
The Configure and Trim is configured as shown be and does not require any adjustments.
Menu
Settings
Passwords
No Pass Words (not configured)
Default display
0 (not configured)
4-20 assign
4-20 1 : Ch1 PV
4-20 2 : Ch3 PV
Manual Mode
Ch1 man mode on: 4-20 1
Initial ch1 manual setting: Bumpless
Ch1 auto entry: timer 2
Ch2 man mode on: 4-20 2
Initial ch2 manual setting: Bumpless
Ch2 auto entry: timer 2
Relay assign/test
Relay 1 timer 1
Relay 2 Ch1 PV
(Relays 3-8 set to missing)
PID Assign
PID A unused
PID B unused
Clock and timers
Clock: Software
Hide Clock N
Hide Rate Y
Hide Flash N
Man trig OK Y
