Maintenance
Troubleshooting
The following table is provided to aid qualified service personnel in troubleshooting problems with the
ICS Page/Party
®
subset.
Table 1. General Troubleshooting
Problem Possible
Solution
Subset is not functional.
Verify DB25 Interconnect cable is properly terminated between
the subset and remote amplifier.
Refer to general troubleshooting section in ICS Page/Party
®
Remote Handset/Speaker Amplifier Station manual for
adjustments and settings that affect ICS Subset operation.
Specifications
Handset
Microphone ........................................................................................................... Dynamic, noise-canceling
Receiver .................................................................................................... Dynamic, hearing aid compatible
Cord ........................................................................................................... Retractile, 6-foot extended, PVC
Material ................................................................................................................................................... ABS
External control .............................................................................................. Push-to-page handset pressbar
Subset Specifications
Construction/finish ........................................................... 0.60 thick Aluminum; safety orange powder coat
Mounting ..................... Desk-edge or similar location; two 0.20-inch (5.1mm) mounting holes (in bracket)
Dimensions ........................................................... 5.00 H
3.19 W 7.01 D inches (127 81 178 mm)
Shipping weight ....................................................................................................................... 4 lbs. (1.8 kg)
Net weight ................................................................................................................................ 2 lbs. (0.9 kg)
Environmental
Temperature range (operation and storage) ............................................. −22º F to 158º F (−30º C to 70º C)
Humidity ...................................................................................................................... 95% non-condensing
Approvals
NRTL certified for use in US and Canada for ....................................................................... UL/CSA 60950
CE Mark
