Specifications, Reference material, Replacement parts – GAI-Tronics 12576-115 Access Panel with VFD, 3x5 User Manual
Page 8: Reference to assembly/model drawings
Pub. 42004-635L2
Model 12576-115 Access Panel with VFD
Page: 8 of 8
\\s_eng\gtcproddocs\standard ioms - current release\42004 instr. manuals\42004-635l2.doc
02/98
Specifications
Electrical
Input voltage ................................................................................................................ 120 V ac/240 V ac
Auto-ranging
Input frequency ........................................................................................................................... 50/60 Hz
Input current draw ................................................................................................ 1 amp max. @ 120 V ac
Line length ........................................................................ 3.0 km with 24 AWG, attenuation = 8.0 dB/km
2.2 km with 26 AWG, attenuation = 11.5 dB/km
Environmental
Operating temperature range................................................................ +32 ºF to +120
°F (0° C to +49° C)
Relative humidity ............................................................................................ Non-condensing 85% max.
Mechanical
Unit dimensions ..................................... 12.25 H
× 19.00 W × 9.13 D inches (311.2 × 482.6 × 232.2 mm)
Unit weight .....................................................................................................................................14 lbs.
Handset material.......................................................................................................................Black ABS
Handset microphone.......................................................................................... Dynamic, noise-canceling
Handset receiver........................................................... Dynamic, hearing aid compatible per FCC part 68
Handset cord .................................................................................... Hytrel, 6-foot (1.8 m) when extended
Handset cradle......................................................................................... Fixed. Built-in off-hook detector
External controls ....................................................................................................... Press-to-page switch
17 configurable push buttons
Replacement Parts
Model Number Description
12509-009
LED Lamp Replacement Kit
54003-001
LED Lamp Holder Tool
54003-002
Lens Removal Tool
61002-007
Replacement Line Cord
Reference Material
Reference to Assembly/Model Drawings
Published by Title
GAI-Tronics Ref. No.
GAI-Tronics
Model 12576-115 Access Panel Outline
72120
