JAM NUT
*
FINE TUNING:
LOOSEN JAM NUT AND THREAD
BOLT IN/OUT TO GIVE THE CABLE
PROPER TENSION. RE-TIGHTEN
JAM NUT.
WARNING - CABLE BOLT MUST BE THREADED
A MINIMUM OF 3/8" WITH JAM NUT TIGHTENED
SECURELY TO ENSURE PROPER CONNECTION.
STOP!
PRIOR TO COMPLETING WEIGHT
CAGE ASSEMBLY, REFER TO MACHINE
MANUAL FOR MACHINE ASSEMBLY.
OWNER'S MANUAL
PAGE 21 ROC-IT WEIGHT CAGE ASSEMBLY
NOTE:
- WRENCH TIGHTEN HARDWARE.
- ACTUAL WEIGHT STACK AND CABLE
MAY VARY. REFER TO MACHINE
MANUAL FOR CORRECT ITEMS.
FRAME ASSEMBLY
*
