HOIST RECOMENDS THE TOWEL HANGER
BE INSTALLED ON THE SIDE OF THE WEIGHT
CAGE MOST CONVIENT FOR THE END USER
OWNER'S MANUAL
PAGE 23 ROC-IT WEIGHT CAGE ASSEMBLY
FRAME ASSEMBLY
NOTES:
- WRENCH TIGHTEN HARDWARE.
- ACTUAL WEIGHT STACK AND CABLE
MAY VARY. REFER TO MACHINE
MANUAL FOR CORRECT ITEMS.
*
*IMPORTANT*
NOW THAT THE ROC-IT WEIGHT CAGE IS COMPLETELY ASSEMBLED, TAKE TIME TO
ENSURE THAT YOUR UNIT IS ASSEMBLED SQUARE AND PERPENDICULAR. USE A LEVEL
TO CHECK THAT THE GUIDE RODS ARE PERPENDICULAR IN BOTH DIRECTIONS.
IF THEY ARE NOT PERPENDICULAR IN BOTH DIRECTIONS, IT WILL BE NECESSARY TO
LOOSEN SOME FRAME HARDWARE TO RE-ALIGN THE FRAME AND RETIGHTEN BOLTS.
