LIGHT CABLING OPTION
78
2
29
CABLE BOLT
42
26
56
78
66
56
65
56
56
26
JAM NUT
12
- WRENCH TIGHTEN OTHER HARDWARE.
FOR CLARITY.
- SOME PARTS MAY HAVE BEEN REMOVED
FRAME ASSEMBLY
NOTE:
- WRENCH TIGHTEN HARDWARE (66) THEN
LOOSEN NUT JUST ENOUGH FOR (42) TO
PIVOT FREELY.
OWNER'S MANUAL
PAGE 09 RS-1302 ASSEMBLY
JAM NUT.
PROPER TENSION. RE-TIGHTEN
FINE TUNING:
BOLT IN/OUT TO GIVE THE CABLE
SECURELY TO ENSURE PROPER CONNECTION.
A MINIMUM OF 3/8" WITH JAM NUT TIGHTENED
WARNING - CABLE BOLT MUST BE THREADED
LOOSEN JAM NUT AND THREAD
