FRAME ASSEMBLY
- SOME PARTS MAY HAVE BEEN REMOVED
SAME TIME.
FOR CLARITY.
NOTE:
- WRENCH TIGHTEN HARDWARE.
- INSTALL CABLE AND PULLEYS AT THE
A MINIMUM OF 3/8" WITH JAM NUT TIGHTENED
FINE TUNING:
PROPER TENSION. RE-TIGHTEN
LOOSEN JAM NUT AND THREAD
OWNER'S MANUAL
PAGE 11
BOLT IN/OUT TO GIVE THE CABLE
SECURELY TO ENSURE PROPER CONNECTION.
RS-1302 ASSEMBLY
WARNING - CABLE BOLT MUST BE THREADED
JAM NUT.
HEAVY CABLING OPTION
JAM NUT
CABLE BOLT
78
56
56
65
29
42
