PART LIST CONTINUED
NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED
OWNER'S MANUAL
PAGE 34 RS-1302 ASSEMBLY
ITEM NO. PART NUMBER DESCRIPTION QTY.
36 026-01F0256 BACKING PLATE 1
37 026-01M0660 SHAFT: 1.00" O.D. X Ø .52" I.D. X 4.69" LG. 1
38 026-01M0729 SHAFT: Ø 1.00" O.D. X Ø .52" I.D. X 2.78" LG. 2
39 026-01M0760 HEAVY FLANGED SPACER: Ø.67" O.D. X Ø.39" I.D. X .50" LG. 2
40 026-01M0836 QUICK RELEASE CABLE LOCK 1/4" 2
41 026-01M1041 SHAFT: .75" O.D. X 5.85" LG. 2
42 026-01M1103 THREADED CABLE ANCHOR Ø1.00" O.D X 2.50" LG. 2
43 026-01M1137 CABLE ANCHOR SHAFT Ø.38"O.D. X 3.06" LG. 1
44 026-01M2320 END CAP: DOMED 2.25" O.D. 2
45 026-01M2322 END CAP DOMED Ø 1.75" O.D. 2
46 026-01P2653 'H' PLATE 1
47 026-01P2920 HEAD BRACKET MOUNT 1
48 026-01P2925 PAD MOUNT BRACKET 2
49 026-01P3470 CABLE SHIELD 1
50 026-01PL0125 E-Z GLIDE PLASTIC SLEEVE 2
51 026-01PL2005 PLUG BUMPER (2 STEM) 3
52 026-01PL2122 OVAL-SHAPED RUBBER FOOT 2
53 026-01PL2197 PLASTIC SCUFF GUARD 11.05" LG. 1
54 026-01PL2237 HAND GRIP 2
55 013-0302008 5/16" SAE FLAT WASHER (WZ) 10
56 013-0402007 3/8" X 22mm FLAT WASHER (WZ) 57
57 013-0102022 3/8" INTERNAL LOCK WASHER 15
58 013-0102028 3/8" CURVED WASHER (WZ) 2
59 013-0102003 1/2" X 27mm SAE FLAT WASHER (WZ) 26
60 011-0101030 5/16"-18UNC X 1.00" BHCS (WZ) 1
61 011-0107029 5/16"-18UNC X 1.00" HHB (WZ) 8
62 011-0311013 3/8-16UNC X .75" SQUARE HEAD (WZ) 1
63 011-0101026 3/8"-16UNC X 1.00" BHCS (WZ) 23
64 011-0407022 3/8"-16UNC X 1.00" HHB (WZ) 2
65 011-0407027 3/8"-16UNC X 1.75" HHB (WZ) 3
66 011-0407058 3/8"-16UNC X 2.00" HHB (WZ) 4
67 011-0107026 3/8"-16UNC X 2.25" HHB (WZ) 2
68 011-0107009 3/8"-16UNC X 2.50" HHB (WZ) 1
69 011-0107051 3/8"-16UNC X 3.50" HHB (WZ) 1
70 011-0107011 5/16"-18UNC X 1.25" HHB (WZ) 2
