GUARD PIN
AS SHOWN.
BE SURE CABLE (3) IS POSITIONED
BETWEEN GUARD PIN AND PULLEY
PULLEY
- SOME PARTS MAY HAVE BEEN REMOVED
- REPEAT ASSEMBLY FOR OPPOSITE SIDE.
FOR CLARITY.
FRAME ASSEMBLY
NOTE:
- WRENCH TIGHTEN HARDWARE.
- INSTALL CABLE AND PULLEYS AT THE
SAME TIME.
OWNER'S MANUAL
PAGE 19
RS-1302 ASSEMBLY
67
56
9
30
23
56
78
3
