IBASE SE-92 User Manual
Page 10
2
SE-92 User Manual
1.2 System Specifications
1.2.1 Hardware Specifications
Model Name
SE-92
System Mainboard
IB912
CPU
5th Generation Intel® Core™ i7-5650U ULT 2.2GHz
5th Generation Intel® Core™ i5-5350U ULT 1.8GHz
5th Generation Intel® Core™ i3-5010U ULT 2.1GHz
Memory
2x DDR3L-1600 SO-DIMM Max. 16GB
I/O Interface
2x DVI-I with EDID emulation function
2x USB 2.0
2x USB 3.0
2x RJ45 for Gigabit LAN
1x RJ45 for RS-232 serial port
2x Microjack audio connectors for Mic-in / Line-out
Power / HDD LED, 1x Power on/off button
1x 4 pin 7-36V DC terminal block
1x clear EDID switch
Storage
1x 2.5” HDD/SSD
1x mSATA
1x NGFF M key 22 x 80mm (2280)
Expansion Slots
1x Mini PCI-E(x1) slot for Wi-Fi/ Bluetooth/ TV Tuner/ 3G /
LTE Wireless options
1x SIM card slot
2x M2(NGFF) slots for Solid State Storage Devices (SSD)/
Wi-Fi/ Bluetooth/ 3G/LTE/ TV tuner options
Power Supply
7V-36V DC-in
Construction
Aluminum + SGCC
Mounting
Standard system bracket
Dimensions
280mm(W ) x 216mm(D) x 46mm(H)
10.7”(W) x 8.6”(D) x 1.8”(H)
Operating
Temperature
-40°C~ 75°C (-40°F~166°F)
Storage
Temperature
-50° ~ 85°C (-58°F~185°F)
Relative Humidity
5~90% @ 45°C, (non-condensing)
Vibration
mSATA: 5 grms / 5~500Hz / random operation
RoHS
Available
Certification
CE, FCC, CCC, UL & e13 Mark
‧
This specification is subject to change without prior notice.
