CSM Configuration
Aptio Setup Utility
Main Advanced Chipset Boot Security Save & Exit
Compatibility Support Module Configuration
→ ← Select Screen
↑↓ Select Item
Enter: Select
+- Change Field
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save
ESC: Exit
CSM Support
CSM16 Module Version
GateA20 Active
Option ROM Messages
Enabled
07.76
Upon
Force BIOS
Boot option filter
Option ROM execution
UEFI and Legacy
Network Do not launch
Storage Legacy only
Video Legacy only
Other PCI device UEFI
CSM Support
Enable/Disable CSM Support.
Boot option filter
This option controls what devices system can boot to.
Network
Controls the execution of UEFI and Legacy PXE OpROM.
Storage
Controls the execution of UEFI and Legacy Storage OpROM.
Video
Controls the execution of UEFI and Legacy Video OpROM.
Other PCI device
Determines OpROM execution policy for devices other than Network, Storage, or Video
