Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
5
IBASE Technology Inc.
1.3 Exploded View of the SE-92 Assembly
1.3.1 Parts Description
Part No. Description
Part No.
Description
1
IB912 motherboard
2
SE-92_perimeter
3
SE-92_rear cover
4
SE-92_front cover
5
SCREW-B30
6
SCREW-B30-B
7
NUTBOSS-S6
8
SE-92_heat sink
9
SE-92_ic heat sink_2
10
SE-92_hdd bracket
11
SE-92_HDD tray
12
SE-92_HDD cover bracket
13
SATA_25HDD
14
SE-92_CPU Heat Sink
15
SE-92_ic heat sink_4
