39
NV-I8GMS Grand Concerto System
· NV-I8GM Grand Concerto main amplifier
· 6 NV-I8GCP Control Pads with white, ivory, almond
and black screwless trim plates
· 1 NV-GRC1 Remote Control
· 6 NV-VEC Visible IR emitters
· 1 NV-I8EZP EZ Port connection hub
· 1 NV-NC1 3 meter network cable
· 1 NV-PC2NA Power Cable, 2 wire, North America
· 1 pr. NV-REM Rack Ear Mounts
NV-I8GXS Grand Concerto Expander System
· NV-I8GX Grand Concerto Expander Amplifier
· 6 NV-I8GCP Control Pads with white, ivory, almond
and black screwless trim plates
· 1 NV-GRC1 Remote Control
· 1 NV-SLC Audio Link cable
· 1 NV-DLC Digital Link cable
·
· 1 pr. NV-REM Rack Ear Mounts
1 NV-PC2NA Power Cable, 2 wire, North America
Grand Concerto Package Contents
Zones 1-6 Power Amplifier Outputs Zone Trigger Outputs
Continuous Average Output Power 80W (40W x 2) Output Power 12V @ 50mA
Two channels driven 30-20kHz @1% THD Outputs 8 (zones 1-8)
Rated Distortion (1/2 power) 0.40%
Rated Impedance 6 Ohms Source Status
Damping Factor 50+ Output Power 3-15 VDC
Frequency Response 20-20kHz 2dB Outputs 6 (Source 1-6)
Zones 1-8 Preamplifier Outputs Power Requirements
Variable output 0-600mV Power Supply- North American 120VAC/ 50Hz
Fixed output 600mV
Power Consumption all channels 600VA (480W) Impedance 600 Ohms
driven to full-rated power
Power Consumption average 100VA (80W) Source Inputs 1-6
operating conditions
input Impedance 20K
Power Consumption no signal 30VA (25W)
Input Sensitivity for rated power 300mV RMS
USA Safety Listing (UL 6500)
Input Overload 3V RMS
Canada Safety Listing (CAN/CSA E60065.00)
CE Listing/SEMKO (EN60065, EN55013,
Emitter Outputs
EN55020, EN6100-3-2, EN6100-3-3/A1)
Source Outputs 6
Sum Outputs 2
Physical Specifications
Output Drive Current 100mA
Unit Size Millimeters 95 x 430 x 340 (LWH)
Output Drive Voltage 12V
Unit Size Inches 3 3/4 x 17 x 13 3/8 (LWH)
Compatible with single and dual emitters
Shipping Size Millimeters 600 x 475 x 380 (LWH)
Shipping Size Inches 23 5/8 x 18 3/4 x 15 (LWH)
System
Unit Weight Kilograms 9.4
System On (output) 12V @ 50mA
Unit Weight Pounds 20.6
External Mute (input) 3-12V DC
Shipping Weight Kilograms 15.5
Shipping Weight Pounds 34.0
Grand Concerto Specifications
Serial Port
Baud Rate
Data Bits
Stop Bits
No Parity
No Flow Control
57,600
8
1
NuVo reserves the right to change specifications without notice
Power Supply- Export 240VAC/60Hz
