35
TABLE 3 – CGM PNEUMATIC START/STOP DIRECTIONAL CONTROL
Item N° Description Part Number
454 1/4" BSP PLUG STEEL 05.5500.454
455 1/2" BSP PLUG STEEL 05.5500.455
456 49X10- 5/8" X 1/2" FLXMPT 90DEG WHD-BRASS 05.5500.456
457 FML 45°SAE / 37°JIC SWVL x PUSH ON BARB-BRASS 05.5500.457
458 C5506X10-5/8" 90DEG UNION ELL WHD-BRASS 05.5500.458
459 3/4" NPTF MALE x 3/4" JIC FEMALE SWVL (Steel) 05.5500.459
460 3/4" 90° PUSH ON BARB x 3/4" MALE NPTF ELBOW 05.5500.460
462 5/8" BLUE PUSH LOCK HOSE 05.5500.462
463 1/4" MALE BSP TO 1/4" NPT FML ADAPTER-BRASS 05.5500.463
464 FML 37° JIC SWVL x PUSH ON BARB-BRASS 05.5500.464
465 90° ELBOW, 3/8" JIC x 1/4" NPTF MALE-BRASS 05.5500.465
466 3/4" BLUE PUSH LOCK HOSE 05.5500.466
467 3/8" BLUE PUSH LOCK HOSE 05.5500.467
147 SOCKET HEAD CAP SCREW, M8 X 100MM 05.0550.147
161 IDENTIFICATION TAGS 05.5500.161
164 PNEUMATIC CONTROL HOUSING 05.5500.164
176 CONTROL KNOB 05.5500.176
