CIO-EXP32 User's Guide Installing the CIO-EXP32
Connecting to a DAS08 Series A/D board
Leave the
A/D BOARD TYPE jumper in the default DAS08 position. Use a C37FF-x cable to connect to DAS08
series boards.
Connecting to a DAS16 Series A/D Board
Set the
A/D BOARD TYPE
jumper to the
DAS16
position.
Connection to a DAS16 series board requires a special 37-conductor cable (C-EXP2DAS16-10) since the pin
relationship of the CIO-EXP32 and DAS16 signals is not 1:1. Refer to the
table below.
C-EXP2DAS16-10 cable pin out
C-EXP2DAS16-10 cable pin out
P1 (MUX) P2
7 23
8 4
9 22
10 3
11 11
12 12
13 13
14 14
15 15
16 16
17 17
18 18
19 19
28 7
29 1
30 30
31 31
32 32
33 33
34 34
35 35
36 36
37 37
N/C Shell Shield
Information on signal connections
General information regarding signal connection and configuration is available in the Guide to Signal
Connections (available at
www.mccdaq.com/signals/signals.pdf ).
