CIO-EXP32 User's Guide
Specifications
Main connector and pin out
Table 7. Connector specifications
Connector type
P1 and P2: 37-pin D type connectors
Compatible cables with connector P1
C37FF-x (connecting to additional CIO-EXP32 boards)
Compatible cables with connector P2
C37FF-x (connecting to a DAS08 board)
C-EXP2DAS16-10 (connecting to a DAS16 board)
Table 8. Connector pin out
Pin
Signal Name
Pin
Signal Name
1
+12V PC Bus
20
-12V PC Bus
2 NC
21 NC
3 NC
22 NC
4 NC
23 NC
5 NC
24 NC
6 NC
25 NC
7
MUX Addr 1
26
NC
8
MUX Addr 2
27
NC
9
MUX Addr 3
28
Power GND
10
MUX Addr 4
29
+5V
11
Output 15
30
Output 7
12
Output 14
31
Output 6
13
Output 13
32
Output 5
14
Output 12
33
Output 4
15
Output 11
34
Output 3
16
Output 10
35
Output 2
17
Output 9
36
Output 1
18
LLGND / Output
37
Output 0
19
NC / LLGND
