Chapter 3 Supported Boards and Subsystems Listed by VI Functions
ADAC LabVIEW VI 212
Advanced Function Channels VIs: (con’t)
4012AD Series: ADC0, Options: Min/Max Channel, Gains = 1, 2, 4, 8
4112AD Series: ADC0, Options: Min/Max Channel, Gains = 1, 2, 4, 8
Advanced Function Expansion Panels VIs:
AL_SetExpPanels.vi & AL_GetExpPanelStruct.vi
Supported Subsystems:
5400 Series: ADC0, Options:
TB5800-16, TB5800-TC or TB5800-64
PCI5500: ADC0, Options: NONE, PCI_TB5500_8
PCI55xx: ADC0, Options: NONE, PCI_TB5500_16, PCI_TB5500_64 or
PCI_TB5500_TC
5508LF: ADC0, Options: NONE, 5508EXi
5508SCi: ADC0, Options: NONE, 5508EXi
5525/50MF: ADC0, Options: NONE, A4012HLEX or A4012TCEX
5800 Series: ADC0, Options: TB5800-16, TB5800-TC or TB5800-64
4012AD Series: ADC0, Options: A4012HLEX, A4012TCEX, A4012CLEX, A4012AMEX,
A4012CSEX, A4012BGEX
4112AD Series: ADC0, Options: A4012WRSX, A4112HCVX
AL_SetExpPanelGains.vi & AL_GetExpPanelGainStruct.vi
Supported Subsystems:
5400 Series: ADC0, Options:
Min/Max Channel, NO Limit on panel gain
PCI55xx: ADC0, Options: Min/Max Channel, NO Limit on panel gain
5508LF: ADC0, Options: Min/Max Channel, NO Limit on panel gain
5508SCi: ADC0, Options: Min/Max Channel, NO Limit on panel gain
5800 Series: ADC0, Options: Min/Max Channel, NO Limit on panel gain
4012AD Series: ADC0, Options: Min/Max Channel, NO Limit on panel gain
4112AD Series: ADC0, Options: Min/Max Channel, NO Limit on panel gain
