Chapter 3 Supported Boards and Subsystems Listed by VI Functions
ADAC LabVIEW VI
213
Advanced Function Thermocouple Configuration VIs:
AL_SetCJList.vi & AL_GetCjList.vi & AL_SetCjGlobal.vi
Supported Subsystems:
5400 Series: ADC0, Options:
Min/Max Channel, BNBS,JNBS,KNBS,SNBS,ENBS,TNBS,RNBS
PCI55xx: ADC0, Options:
Min/Max Channel, BNBS,JNBS,KNBS,SNBS,ENBS,TNBS,RNBS
5508SCi: ADC0, Options:
Min/Max Channel, BNBS,JNBS,KNBS,SNBS,ENBS,TNBS,RNBS
5508TC: ADC0, Options:
Min/Max Channel, BNBS,JNBS,KNBS,SNBS,ENBS,TNBS,RNBS
5525/50MF: ADC0, Options:
Min/Max Channel, BNBS,JNBS,KNBS,SNBS,ENBS,TNBS,RNBS
5800 Series: ADC0, Options:
Min/Max Channel, BNBS,JNBS,KNBS,SNBS,ENBS,TNBS,RNBS
4012AD Series: ADC0, Options:
Min/Max Channel, BNBS,JNBS,KNBS,SNBS,ENBS,TNBS,RNBS
4112AD Series: ADC0, Options:
Min/Max Channel, BNBS,JNBS,KNBS,SNBS,ENBS,TNBS,RNBS
Advanced Function DMA Configuration Vis:
AL_SetDmaChan.vi & AL_GetDmaChan.vi
Supported Subsystems:
5400 Series: ADC0, Options:
DISABLED, DMA5, DMA6, DMA7
5500HR: ADC0, Options:
DISABLED, DMA1, DMA2, DMA3
5508LC: ADC0, Options:
DISABLED, DMA1, DMA2, DMA3
5508LF: ADC0, Options:
DISABLED, DMA1, DMA2, DMA3
5508SCi: ADC0, Options:
DISABLED, DMA1, DMA2, DMA3
5508SHR: ADC0, Options:
DISABLED, DMA1, DMA2, DMA3
5516DMA: ADC0, Options:
DISABLED, DMA1, DMA2, DMA3
5525/50MF: ADC0, Options:
DISABLED, DMA1, DMA2, DMA3
5800 Series: ADC0, Options:
DISABLED, DMA5, DMA6, DMA7
Advanced Function IRQ Configuration VIs:
AL_GetIrqLevel.vi & AL_SetIrqLevel.vi
Supported Subsystems:
5400 Series: ADC0, Options:
DISABLED, IRQ3, IRQ5, IRQ7, IRQ10, IRQ11, IRQ15
5500HR: ADC0, Options:
DISABLED, IRQ2, IRQ3, IRQ4, IRQ5, IRQ6, IRQ7
5508LC: ADC0, Options:
DISABLED, IRQ2, IRQ3, IRQ4, IRQ5, IRQ6, IRQ7
5508LF: ADC0, Options:
DISABLED, IRQ2, IRQ3, IRQ4, IRQ5, IRQ6, IRQ7
5508SCi: ADC0, Options:
DISABLED, IRQ2, IRQ3, IRQ4, IRQ5, IRQ6, IRQ7
5508SHR: ADC0, Options:
DISABLED, IRQ2, IRQ3, IRQ4, IRQ5, IRQ6, IRQ7
5508TC/BG/RTD: ADC0, Options:
DISABLED, IRQ2, IRQ3, IRQ4, IRQ5, IRQ6, IRQ7
5516DMA: ADC0, Options:
DISABLED, IRQ2, IRQ3, IRQ4, IRQ5, IRQ6, IRQ7
5525/50MF: ADC0, Options:
DISABLED, IRQ2, IRQ3, IRQ4, IRQ5, IRQ6, IRQ7
5600 Series ACI, DCI, CCI, TTL: DIN0, Options: DISABLED, IRQ2, IRQ3, IRQ4, IRQ5, IRQ6, IRQ7
5800 Series: ADC0, Options:
DISABLED, IRQ3, IRQ5, IRQ7, IRQ10, IRQ11, IRQ15
