Chapter 2 Analog Output-VIs
ADAC LabVIEW VI 52
$'$& $2 &RQILJ FRQW
DATA OFFSET (BIPOLAR:0) DATA OFFSET is a numeric value that sets the
hardware data offset configuration of the device.
The available options are:
0:BIPOLAR Bipolardata +/- V
1:UNIPOLAR Unipolar data 0-V
The default DATA OFFSET is 0:BIPOLAR
error in (no error) Error in describes error conditions occurring before this VI executes.
This cluster defaults to no error.
DATA RANGE (-10/10:0) DATA RANGE is a numeric value that sets the hardware
voltage data range of the device.
The available options are:
0:-5_5 +/- 5V
1:0_10 + 0-10V
2:-10_10 +/- 10V
The default DATA OFFSET is 2:-10_10
Element (0) Element is a numeric value that specifies the DAQ hardware subsystems
DAC number. For a two DAC board the first DAC would be Element 0 and the second
DAC would be element 1.
The default Element is 0.
Device Handle Device Handle is a numeric value that identifies the board's D/A
subsystem to be acted upon in subsequent VI subsystem calls.
error out Error out contains error information. If the error in cluster indicated an error,
the error out cluster contains the same information. Otherwise, error out describes the
error status of this VI.
