58
TECHNICAL SPECIFICATIONS
#1: With two 20 feet (6.1 m) duct with one 90° bend each, supply grill and return grill with
filter (0.30 IWG (75 Pa) external static pressure)
#2: Confirm pressure drop of duct, grills and filter with manufactures specifications.
Electronic
Features
Operation Wall Mounted Controller with LCD
display
Control Electronic
Electronic
Characteristics
Voltage requirement 208/230 V, 1 phase, 60 Hz
Min.- Max. voltage Min. 198 V, Max. 253 V
Recommended fuse size 20 A
Cooling Capacity and Power Consumption
Evaporator: 80 °F
(27 °C), 50 %RH /
Condenser: 95 °F
(35 °C), 50 %RH
Total cooling capacity 25,000/25,000 Btu/h (7,320/7,320 W) #1
Sensible cooling capacity 18,000/18,000 Btu/h (5,280/5,280 W) #1
Power consumption 2.90/2.90 kW #1
Current consumption 13.6/12.6 A #1
Evaporator: 72 °F
(22 °C, 50 %RH /
Condenser: 95 °F
(35 °C), 50 %RH
Total cooling capacity 25,000/25,000 Btu/h (7,320/7,320 W) #1
Sensible cooling capacity 18,900/18,900 Btu/h (5,580/5,580 W) #1
Power consumption 3.20/3.20 kW #1
Current consumption 15.0/15.0 A #1
SEER 14/14 #1
Evaporator Type of fan Centrifugal Fan
Air flow High 850/950 CFM (1,145/1,615 m
3
/h)
Low 700/800 CFM (1,190/1,360 m
3
/h)
Max. External static pressure 0.6 IWG (150 Pa)
Motor output
0.21 kW
Condenser Type of fan Centrifugal Fan
Air flow High 1,490/1,600 CFM (2,530/2,720 m
3
/h)
Low 1,190/1,300 CFM (2,020/2,210 m
3
/h)
Max. External static pressure 0.5 IWG (125 Pa)
Motor output
0.35 kW
Compressor Type Hermetic Swing Inverter
Refrigerant Type R-410A
Amount 2.31 lb (1.05 kg)
Dimension W x D x H (without flange) 53 x 32 x 20 in (1,346 x 813 x 508 mm)
W x D x H (with flange) 57 x 36 x 20 in (1,448 x 914 x 508 mm)
Weight Net / Shipping 310/353 lb (140/160 kg)
Condensate
Pump Capacity
Pump Rate 5.0 gal/h (19 L/h)
Head 4 ft (1.2 m)
Operating
Condition Range
Evaporator Max. Inlet Air 95 °F (35 °C), 50 %RH
Min. Inlet Air 60 °F (15.5 °C), 50 %RH
Condenser Max. Inlet Air 113 °F (45 °C)
Min. Inlet Air 50 °F (10 °C)
Maximum Duct
Length
Cold duct hose 120 ft (36.6 m) #2
Hot duct hose 90 ft (27.4 m) #2
Maximum Sound
Level
Under ceiling tile with
evaporator duct
55/55 dB (A)
