12
Technical Data
Dimensions
RXW 350 RXW 480
Operating mode Cooling and heating
Nominal cooling capacity * kW 3.49 4.78
Nominal heating capacity ** kW 3.78 5.17
Operating range °C +16 to +30
Refrigerant R 410A
Circulating air volume per speed m³/h 460/ 550 / 620
Sound pressure level per speed *** dB(A) 34 / 37 / 41 37 / 41 / 44
Power supply V/Ph/Hz 230 / 1 / 50
Protection type IP X0
Electr. nominal power consumption cooling* kW 1.07 1.49
Electr. nominal power consumption heating** kW 1.09 1.52
Electr. nominal current consumption cooling A 4.91 6.91
Electr. nominal current consumption heating A 4.99
Refrigerant connection injection pipe Inches (mm) 1/4“ (6.35)
Refrigerant connection suction pipe Inches (mm)
Refrigerant pipe, length max. m 10
Refrigerant pipe, height max. m 5
Dimensions height mm 285
width mm 830
depth mm 205
Weight kg 11.0
Serial number 685... 686...
Ref. No. 1619100 1619110
1/2“ (12.7)
7.01
480/ 560 / 620
* Room temperature DB 27, WB 19 °C; outside temperature DB 35 °C, WB 24 °C in combination with RKS 435 H or RKS 448 H
** Room temperature DB 20, WB 14 °C; outside temperature DB 7 °C, WB 6 °C in combination with RKS 435 H or RKS 448 H
*** Distance
1m
RXW 350 / RXW 480
830
285
205
