Seaward Apollo 500 - Manual (Page 18)

Touch Current
Test Voltage:
Display Range:
Measurement Range:
Resolution:
Operating Error:
Frequency Response:
Supply Voltage, maximum load
current 16A
0.00mA to 3.50mA
0.10mA to 3.50mA
0.01mA
+/-5% of reading +/- 2 digits
DC to 2.5 kHz
Load Power/Current
Test Voltage:
Display Range:
Measurement Range:
Resolution:
Operating Error:
Supply Voltage, maximum load
current 16A
0.00 - 16.00A
0.50 - 16.00A
0.01A
+/-10% of reading +/- 5 digits
Lead Test
Test Voltage:
Test: 5V DC nominal
Live / Neutral checks for o/c,
s/c and crossed
Power Socket Test
Input voltage range:
195V – 253V AC
Indicates configuration of
voltage potential:-
Line potential phase to earth
Line potential phase to neutral
Line potential neutral to earth
RCD Test
Test Voltage:
Test Current:
Test Current Accuracy:
Display Range:
Measuring Range:
Resolution:
Operating Error:
230V +10%, -15%
30mA / 150mA rms sinusoidal
30mA -10% +0%,
150mA +10, -0%
0 – 2000ms
1ms – 2000ms
1ms
±1ms
External Leakage
Test Voltage:
Display Range:
Measuring Range:
Resolution:
Operating Error:
Connected to External Adapter
0mA - 9.99mA
0.25mA - 9.99mA
0.01mA
+-5% of reading +-2 digits
14. Useful Information
14.1 Factory Set Test Sequences
Test
Visual Earth Continuity Insulation
PE Conductor
Current
Touch Current
Substitute
Leakage
Wiring
RCD
Trip
Time
Name
Duration
(s)
Limit
(Ω)
Duration
(s)
Voltage
Limit
(MΩ)
Duration
(s)
Limit
(mA)
Duration
(s)
Limit
(mA)
Duration
(s)
Limit
(mA)
Limit
(ms)
Portable/Handheld/IT CLI Yes 5 0.1 2 500 1
Portable/Handheld/IT CLII Yes 2 500 2
Fixed Appliance CLI Yes 2 0.1 5 500 1
Fixed Appliance CLII Yes 5 500 2
IEC Lead 2m Yes 5 0.2 2 500 1 Yes
13A 5m Surge Protected Lead Yes 5 0.2 2 250 1 Yes
