Environmental conditions, 2 other information – Seaward Apollo 500 User Manual
Page 19
13A 25m Ext Lead 30mA RCD
Yes
5
0.5
5
0.8
30
Portable CLI PE Current
Yes
5
0.5
2
250
1
5
0.8
Portable CLII Touch Current
Yes
2
250
2
5
0.3
IT Equip CLI PE Current
Yes
5
0.1
2
250
1
5
3.5
IT Equip CLII T ouch Current
Yes
2
250
5
0.3
13A 6m Mains Lead
Yes
5
0.2
2
500
1
Yes
13A 12m Mains Lead
Yes
5
0.3
2
500
1
Yes
13A 24m Mains Lead
Yes
5
0.5
2
500
1
Yes
Mov/Stat CLI 500V Insulation
Yes
5
0.1
2
500
1
Mov/Stat CLII 500V Insulation
Yes
2
500
2
Mov/Stat CLI PE Current
Yes
5
0.1
2
250
1
5
3.5
Mov/Stat CLII Touch Current
Yes
2
250
2
5
3.5
110V Handheld/Portable CLI
Yes
5
0.1
2
500
1
2
0.8
110V Handheld/Portable CLII
Yes
2
500
2
2
0.3
110V Movable/Stationary CLI
Yes
5
0.1
2
500
1
2
3.5
110V Movable/Stationary CLII
Yes
2
500
2
2
0.3
110V 25m Lead
Rpe&Insulation
Yes
5
0.5
2
500
1
Visual Only
Yes
14.2 Other Information
Parameter
Default
Min
Max
Earth Continuity P/F limit (Ω)
0.1
0.01
19.99
Earth Continuity Duration (s)
5
2
30
Insulation Resistance P/F limit (MΩ)
1
0.01
19.99
Insulation Resistance Duration (s)
5
2
30
Substitute Leakage P/F limit (mA)
0.75
0.25
15
Substitute Leakage Duration (s)
5
2
30
IEC Cord Earth Continuity P/F limit (ohms)
0.1
0.01
5
IEC Cord Insulation P/F limit (MΩ)
1
0.01
19.99
Touch Current P/F limit (mA)
0.25
0.25
3.50
Touch Current Duration (s)
5
2
30
PE Conductor Current P/F limit (mA)
0.75
0.25
19.99
PE Conductor Current Duration (s)
5
2
30
External Adapter Continuity (Ω)
0.1
0.01
5
External Adapter Leakage (mA)
0.75
0.25
9.99
External Adapter Duration (s)
5
2
30
RCD 30mA trip time (ms)
200
1
2000
RCD 150mA trip time (ms)
40
1
40
Number of tests in a test sequence
1
60
Characters in a test sequence name
1
30
Characters in a User Test name
1
15
Characters in a User Test Unit
15
Total number of Test Sequences
100
Test Results Memory (Mbytes)
300
Test Results (typical)
30000
Sites
100
Characters in Site name
1
15
Locations
100
Characters in Location name
1
15
Users
50
Characters in User name
1
15
Comments List
100
Characters in Comment
25
Characters in Asset ID
1
15
15.
The Apollo 500 has been designed to perform tests and measurements in a dry environment.
Maximum barometric elevation for making measurements is 2000M.
Pollution degree 2 according to IEC 60529.
Electromagnetic compatibility (EMC). Interference immunity and emitted interference conforming to IEC 61326-1.
Operating temperature range of 0 to 40 degrees C, without moisture condensation.
