6 – Interfacing with your Audio Software
TASCAM US-122 —
21
Setting the Sample Rate and Bit Depth
The US-122 supports sample rates of
44.1kHz and 48kHz. In the
Audio
Control Panel , select the pull-down
menu for Sample Rate and select either
44.1 kHz or 48 kHz .
The US-122 control protocol includes
two separate drivers for 16-bit or 24-bit
operation. This selection is made in the
Audio Control Panel (see the illustra-
tion).
NOTE
The bundled Cubasis VST supports only 16-
bit audio. If you want to record in 24-bit
mode you will need to upgrade to Cubase
VST or another application that supports
24-bit audio.
Input Enabling
You will need to enable the inputs on
Cubasis. Open the
Audio Input window
(see the illustration here) and select one
mono track or a stereo pair.
Note that Cubasis supports only one
input for recording (though this can be a
mono or stereo track).
Then select the inputs on Cubasis’ inter-
nal mixer. If you’re recording a mono
input, left click on the input selector
above the channel strip and select the
desired input
L or R . If you’re recording a
stereo track, the inputs will both be
selected automatically Verify that the
designated channels’ inputs (
IN ) are
selected, and the associated channels are
receiving signal.
