4
— TASCAM US-122
1 – Introduction
Overview
The US-122 is a USB powered audio/
MIDI interface designed for Digital
Audio Workstation (DAW) software
applications. Its design incorporates a
two-input, two-output 24-bit audio inter-
face with balanced inputs, input inserts,
guitar impedance matching, phantom
powering, and a 16-channel MIDI inter-
face. Because the US-122 is USB-based, it’s
the ideal companion to any desktop- or
laptop-based digital recording setup.
And since it’s as compact, like a laptop,
requiring no additional power source, it
can be combined with one to create a
complete portable digital audio worksta-
tion solution.
Features
The input section comprises a 24-bit
audio interface, capable of streaming
two simultaneous channels of audio into
your computer. Inputs include two bal-
anced XLR mic inputs with phantom
power capability, two 1/4” balanced line
inputs (switchable to high-impedance
unbalanced, for direct input of a guitar,
bass or other hi-Z source), with TRS inserts on each input channel. Outputs
include a pair of unbalanced line outputs
on RCA connectors, and a separate head-
phone output.
The US-122 also features MIDI input
and output ports, allowing you to send
and receive data between your computer
and other MIDI-equipped devices.
What’s in the package
The US-122 package contains the fol-
lowing items in addition to the main unit
and this manual. When opening the
package, please make certain that all the
included items are present. If anything is
missing, contact the dealer where you
purchased it.
• US-122 main unit
• USB cable
• CD-ROM containing drivers (Win-
dows and Mac OS), Cubasis, and doc-
umentation
• CD-ROM containing Gigastudio 24
and sample soundware (for Windows
only).
• Warranty and registration cards for
US-122
• Registration card for Cubasis
• TEAC address list
