Display
Modifiable Description
*USB-1 Country Code
USB-1 Country
NO
For CPU 1 the country code of the USB KB that the device reports
itself as being. This is the last USB KB country applied to the
remote host. Most hardware is not localized and thus this value will
be zero (0), which is displayed As “Not Supported.”
USB-1 Device Enum
NO
For CPU 1 a bit pattern that indicates which ports have been
enumerated at the device side. The bits are laid out as Bit0-KB,
Bit1=MS, Bit2=TBLT, Bit3=DWNLD, Bit4=Daughter Card_KB, Bit5=
Daughter_MS, Bit6=Daughter_TBLT.
Display
Modifiable Description
*PS2-1 Devices
PS2-1 KB Scan Code
NO
For CPU 1 indicates a value of 1, 2 or 3 for the scan code that the
device is told to emulate. If 0, then the keyboard is not properly
connected to the CPU.
PS2-1 Mouse
NO
For CPU 1 indicates a value of 0, 3 or 4 for the mode that the
device is told to emulate. If 255, then the mouse is not properly
connected to the CPU.
Display
Modifiable Description
*USB-2 Country Code
USB-2 Country
NO
For CPU 2 the country code of the USB KB that the device reports
itself as being. This is the last USB KB country applied to the
remote host. Most hardware is not localized and thus this value will
be zero (0), which is displayed As “Not Supported.”
USB-2 Device Enum
NO
For CPU 2 a bit pattern that indicates which ports have been
enumerated at the device side. The bits are laid out as Bit0-KB,
Bit1=MS, Bit2=TBLT, Bit3=DWNLD, Bit4=Daughter Card_KB, Bit5=
Daughter_MS, Bit6=Daughter_TBLT.
