The Future of Access and Control
February 2010
17
REVISION C
Appendix B: Out of Band Control
For Apple Keyboard Users
LCD Navigation Pad
LCD System Information
and Programming
If using an Apple Keyboard, once the firmware has been installed into the OriginKVM 8250, for
User 1
use the
UP arrow
on the Navigation Pad to reach
*Out of Band CTRL from the main menu. Then
use the
RIGHT arrow
to reach
User 1 Alt. HOT Key NOT USED. If not using an Apple Keyboard,
leave this setting as it is.
enter
User 1
Alt. HOT Key NOT USED
To make a change from the
Alt. HOT Key menu, press enter. Use the UP
or
DOWN arrow
to
access the available alternate hot key options:
Alt. HOT Key (F13, F14, F15, LEFT CTRL, RIGHT CTRL or R or L CTRL).
Press
enter to implement the change. Each keyboard is handled separately. The user may need to
repeat the procedure for User 2.
LEFT
CONTROL
RIGHT
CONTROL
F13
F14 F15
APPLE KEYBOARD
Alternate Key Strokes
