TRI TOOL INC.
92-0628 : Rev. 961122
Parts List, Model 308E Tube Squaring Machine (P/N 02-2214)
Item
Part
No.
No.
Description
Qty
1.
19-0737
HOUSING
1
2.
20-0334
SHAFT, INTERNAL
1
3.
20-0592
SHAFT
1
4.
20-0612
SHAFT, DRIVE
1
5.
21-0457
HEAD, FACING
1
6.
24-0573
PLATE ASSY, FEED
1
7.
24-1414
PLATE, END
1
8.
27-0538
ADAPTER, MOTOR
1
9.
28-0160
SEAL, OIL
1
10.
29-0002
BEARING, BALL
1
11.
29-0020
BEARING, BALL
1
12.
29-0067
BEARING, THRUST
2
13.
29-0135
BEARING, BALL
1
14.
29-0185
RACE, INNER
2
15.
29-0186
RACE, BEARING
1
16.
29-0187
BEARING, ROLLER
1
17.
30-0060
RING, RETAINING, EXTERNAL
1
18.
30-0415
RING, HOIST
1
19.
30-1089
RING, RETAINING, INTERNAL
1
20.
31-0037
KEY, 3/16 SQUARE
1
21.
31-0152
KEY, TORQUE
1
22.
33-0019
SCREW, CAP, #8-32 X 3/8", ZP
2
23.
33-0041
SCREW, CAP, 1/4-20 X 7/8", ZP
4
24.
33-0059
SCREW, CAP, 5/16-18 X 1 3/4", ZP
3
25.
33-0071
SCREW, CAP, 3/8-16 X 1", ZP
7
26.
33-0072
SCREW, CAP, 3/8-16 X 1 1/4", ZP
4
27.
33-0469
SCREW, SET, #6-32 X 3/8", CUP PT
4
28.
33-0503
SCREW, SET, 1/4-20 X 1/2", CUP PT
2
29.
33-0507
SCREW, SET, 1/4-20 X 1", CUP PT
27
30.
33-1486
SCREW, FEED
1
31.
33-1949
SCREW, SET, BRASS TIP, 1/4-20 X 1/4"
1
32.
34-0106
WASHER, THRUST
4
33.
34-0302
WASHER, THRUST
1
34.
35-0237
NUT, BEARING RETAINING
1
35.
35-0255
NUT, THRUST
1
36.
39-0784
GEAR, SPUR, DRIVE
1
37.
39-0787
GEAR, SPUR
1
38.
42-0081
KNOB, FEED
1
