Tri Tool 308 Tube Squaring - Manual (Page 35)

35
Model 308, Tube Squaring Machine
92-0628 : Rev. 961122
Parts List, Clamping Kit, Air (P/N 05-1315)
Item Part
No. No. Description Qty
1. 24-1459 PLATE, FLOW CONTROL MOUNT 1
2. 33-0034 SCREW, CAP, #10-24 X 1 1/2" 2
3. 33-0050 SCREW, CAP, 1/4-20 X 3" 4
4. 33-0056 SCREW, CAP, 5/16-18 X 1" 4
5. 44-0461 SPACER 1
6. 53-0061 VALVE, 4 WAY, LEVER 1
7. 53-0064 MUFFLER 2
8. 53-0065 VALVE, FLOW CONTROL 1
9. 53-0066 DIAL, FLOW METER 1
10. 53-0067 VALVE, FLOW CONTROL 1
11. 54-0108 FITTING, NIPPLE 1
12. 54-0149 FITTING, QUICK DISCONNECT 1
13. 54-0353 ELBOW, 90 DEG., TUBE 3
54-0382 CYLINDER ASSY, SHAFT 1
14. 20-0616 SHAFT 1
15. 30-2315 CYLINDER, AIR 1
16. 35-0107 NUT, JAM, 5/8-18 1
54-0201 CAP, PLASTIC 1
55-0185 TUBE, PLASTIC 8"
NOT SHOWN:
