Page 16
Installation Guide
2.
Remove the plastic covering the dome cover. Final installation will look like the illustration
below.
Step 6: Connect to the Network
Connect the other end of the network cable to a switch or injector. Then, connect the switch or
injector to a network or PC and a power source. See Power-over-Ethernet (PoE) example
connection diagram below.
Network
AC Power
Source
PoE Injector /
PoE Switch
Power Cable
Ethernet Cable
Ethernet Cable
(Data + Power)
Ethernet Cable
(Data)
Camera
In case of using a non-PoE switch, power up the camera using a power adapter (not supplied).
As needed, power up the other connected devices.
Step 7: Access the Camera Live View
Refer to the camera Hardware Manual downloadable from the website
for more
information.
