Installation Guide
Waterproof Solution with Naked Cable
This section describes the procedures in using the bundled cable gland and an exterior-grade
Ethernet cable.
1.
Disassemble the cable gland as shown below:
2.
Insert the clamping nut into the Ethernet cable.
3.
Insert the sealing insert with claw.
Body
(with Washer)
Sealing Insert
with Claw
Clamping
Nut
