8939FCA/FCB — Instruction Manual 19
8939FCA and 8939FCB Applications
Figure 7. 9 Channel Mux/Demux Application
8772_04r1
8939FCA
8943CF
Fiber Out 1 to 1610nm
Fiber In 1
from 1610nm
Fiber In 2
from 1590nm
Fiber In 3
from 1570nm
Fiber In 4
from 1550nm
Fiber Out 3 to 1570nm Fiber Out 4 to 1550nm Fiber Out 2 to 1590nm Fiber Out 1 to 1530nm Fiber Out 3 to 1490nm Fiber Out 4 to 1470nm Fiber Out 2 to 1510nm
Electrical
Inputs
Multiplexer
Demultiplexer
Connector J6 Connector J4
8943CF
SFP-CWDM3G-3-K 1550nm & 1570nm
Fiber In 1
from 1530nm
Fiber In 2
from 1510nm
Fiber In 3
from 1490nm
Fiber In 4
from 1470nm
Connector J6
SFP-CWDM3G-4-K 1590nm & 1610nm
Connector J4
SFP-CWDM3G-1-K 1470nm & 1490nm SFP-CWDM3G-2-K 1510nm & 1530nm
8943FC
Connector J4
Connector J6
Connector J4
SFP-13103G-M1DRX-K
1270 > 1610nm
SFP-13103G-M1DRX-K
1270 > 1610nm
SFP-13103G-M1DRX-K
1270 > 1610nm
SFP-13103G-M1DRX-K
1270 > 1610nm
Connector J6
COM
EXP
CH1 1470nm
CH2
1490nm
CH4
1530nm
CH3 1510nm
CH4
1570nm
CH5 1550nm
CH8
1610nm
CH7 1590nm
8939FCA
COM
EXP
CH1 1470nm
CH2
1490nm
CH4
1530nm
CH3 1510nm
CH4
1570nm
CH5 1550nm
CH8
1610nm
CH7 1590nm
8943FC
Electrical
Outputs
Location A
Location B
8935FC Fiber Inputs
1 2
4 3
IN
IN
8935CF Fiber Outputs
1 2
4 3
OUT
OUT
GeckoFlex Fiber
-Ready Module
SFP-13103G-M1DTX
GeckoFlex Fiber
-Ready Module
1310-DRL Submodule
Ch 1 Ch 2 Ch 3 Ch 4 Ch 1 Ch 2 Ch 3 Ch 4
Coax In
Fiber Out
Ch 1
Coax Ouputs
Ch 3 Ch 4 Ch 2
Ch 1 Ch 2 Ch 3 Ch 4
Ch 1 Ch 3 Ch 4 Ch 2
Ch 1 Ch 2 Ch 3 Ch 4
Note: In this configuration (8959FCA to 8939FCA utilizing CWDM transmitters), if the distance between 8939FCA modules is l
ess than 12 km (7.5 m),
a 3 dB attenuator must be installed somewhere between the COM ports on the 8939FCA modules to prevent overdriving the receiver
causing bit errors
to occur on the link.
*
Distance of up to 50km
( see note
for inline
attenuation
requirements)
*
Single-mode fiber cable
