background image

8949MDA-CXF/-SXF — Instruction Manual

23

Cabling

Cabling

Cabling to the 8949MDA-CXF or 8949MDA-SXF module is done on the
8900WFR-XFR rear module.

For fiber optic submodule option cabling, refer to the following:

Before making fiber optic connections, refer to the

Fiber Optic Cleaning

Requirement on page 17

.

For available submodule types, refer to

Table 2 on page 16

.

Attenuation requirements may be necessary on some fiber connections.
Refer to

Attenuation Requirements on page 52

.

Cabling of the rear module depends on what fiber optic submodule option
is installed as listed below:

8949MDA-CXF and 8949MDA-SXF without fiber optic submodule
option (electrical only),

8949MDA-CXF and 8949MDA-SXF with Dual Receiver submodule

8949MDA-CXF and 8949MDA-SXF with Dual Transmitter submodule,
and

8949MDA-CXF and 8949MDA-SXF with Transceiver submodule.

The 8949MDA-CXF and the 8949MDA-SXF will accept any of the video
standards listed in the input specifications in

Table 5 on page 50

.

Table 3

gives the inputs and the possible video output connections for the

8900WFR-XFR, the rear modules used with the 8949MDA front modules.
The rear cabling is illustrated in

Figure 12 on page 24

for the

8949MDA-CXF and

Figure 13 on page 24

for the 8949MDA-SXF module.

Table 3. 8900WFR-XFR Rear Module Video Cabling

Fiber Optic

Submodule Option

Video

Inputs

Coax

Video

Outputs

Coax

8949MDA-CXF

PAL/NTSC

Monitoring

Outputs

8949MDA-SXF

SDI

Monitoring

Outputs

Fiber 1

Input or Output

Fiber 2

Input or Output

No submodule

J9

J1, J3, J5, J7

J2, J4, J6, J8

J2, J4, J6, J8

N/A

N/A

Dual Receiver

J9

J1, J3, J5, J7

J2, J4, J6, J8

J2, J4, J6, J8

RX: 1270 to 1610 nm

RX: 1270 to 1610 nm

Dual Transmitter (1310nm)

J9

J1, J3, J5, J7

J2, J4, J6, J8

J2, J4, J6, J8

TX: 1310 nm

TX: 1310 nm

Dual Transmitter (CWDM)

1470/1490nm

J9

J1, J3, J5, J7

J2, J4, J6, J8

J2, J4, J6, J8

TX: 1470 nm

TX: 1490 nm

Dual Transmitter (CWDM)

1510/1530nm

J9

J1, J3, J5, J7

J2, J4, J6, J8

J2, J4, J6, J8

TX: 1510 nm

TX: 1530 nm

Dual Transmitter (CWDM)

1550/1570nm

J9

J1, J3, J5, J7

J2, J4, J6, J8

J2, J4, J6, J8

TX: 1560 nm

TX: 1570 nm

Dual Transmitter (CWDM)

1590/1610nm

J9

J1, J3, J5, J7

J2, J4, J6, J8

J2, J4, J6, J8

TX: 1590 nm

TX: 1610 nm

Transceiver

J9

J1, J3, J5, J7

J2, J4, J6, J8

J2, J4, J6, J8

RX: 1310 nm

TX: 1310 nm
