Page 81: Introduction, Chapter 6
DMC 1000 Digital Media Camcorder User’s Guide (v4.0)
81
Chapter 6 - Audio setup
Chapter 6
Audio setup
6.1 Introduction
Audio signals from various sources can be recorded onto four audio recording channels. These
channels are identified in the menus as:
•
ch1, ch2, ch3 and ch4
The sources used for recording can be:
•
the front microphone,
•
the line or mic. inputs at the rear of the camcorder,
•
AES digital audio signals applied to the BNC input at the right-rear of the camcorder,
•
one of eight embedded SDI audio channels,
•
an optional wireless microphone receiver (one or two channels), or
•
one of three aliased intercom channels (Sidetone, Engineering, Production or Program).
Audio signals are output:
•
on the rear 5-pin XLR audio output connector,
•
as embedded channels in the (HD-)SDI output signal, or
•
as AES/EBU digital audio signals on the BNC connector on the right-rear of the camcorder.
The following pages will tell you how to:
•
connect the inputs and set input sensitivity,
•
select recording channel sources and set recording levels,
•
monitor channels and sources,
•
select output channels or sources and
•
set up an intercom configuration.
