LDK 4426 3G Camera Triax to 3G Fiber Converter User’s Guide (v2.0)
17
Chapter 1 - Installation
1.4 Location of connectors and indicators
Triax
connector
Indicator
panel
Mains
connector
Fiber
connector(s) *)
Earth
pin
*) Can be either two mono (dark) fiber connectors or a single hybrid fiber
connector.
